Air Data Test Set
MPS31C – Air Data Test Set
Independent control of Altitude & Airspeed
Fully RVSM compliant with 12 months recalibration period
Integrated pressure and vacuum pumps with 5000 hours warranty
Universal AC powered and internal 2 hours battery back-up
Optional mutiple Ps &Pt ports with automatic line switching
Rugged Flightline unit with wheels and stowable tow handle
MPS39 / 40C – Air Data Test Set
3 independent channels for Altitude, Airspeed and Angle of Attack
Fully RVSM compliant with 12 months recalibration period
Integrated pressure and vacuum pumps with 5,000 hours guarantee
Universal AC powered and internal 4 hours battery back-up
Multiple Ps, Pt & AOA ports with automatic line switching option
Rugged flightline unit with wheels and stowable tow handle
MPS43 / 43B – Air Data Test Set
Ultra Compact Automatic Air Data Test Set
Ps up to 55,000 ft, Pt up to 550knots
RVSM compliant with 12 months recalibration
Universal AC powered and internal battery back up
Lightweight rugged case, carry to cockpit design
MPS45 – Air Data Test Set
Control of Altitude and Airspeed from local or remote
RVSM compliant with 18 months recalibration
Integrated pressure and vacuum pumps with 5,000hours warranty
Universal AC powered with internal 2 hours battery back-up
Optional mutiple Ps & Pt ports with automatic line switching
Rugged flightline unit with wheels and stowable tow handle
Suitable replacement for MPS31C (Legacy Air Data Test Set)
MPS46s / 56 – Laboratory Air Data Test Set
Independent control of Altitude and Airspeed
Exceeds RVSM accuracy with 12 months recalibration
GPIB, RS232 and USB interfaces for ATE systems compatibility
User programmable safety limits and multiple test programmes
Internal Pumps (MPS46P/ MPS46PM), single channel and high flow rate variants available
19 inches rack mount 2U high ( MPS46 / MPS46P/ MPS46 M/ MPS46PM/ MPS46H)
19 inches rack mount 3U high (MPS56)
MPS49 – Air Data Test Set
3 independent channels for Altitude, Airspeed and Angle of Attack
RVSM compliant with 18 months recalibration
Integrated pressure and vacuum pumps with 5,000 hours guarantee
Universal AC powered and internal 2 hours battery back-up
Optional multiple Ps, Pt and AOA ports with automatic line switching
Rugged flightline unit with wheels and stowable tow handle
Suitable replacement for MPS39C (Legacy Air Data Test)
BCE14 / 15 – Digital Tachometer Tester
Range: 0 – 12,000 RPM
Reading accuracy: ± 1 RPM
Speed stability: ± 0.1% of reading
Up to 3 independent drives (BCE 15)
Selectable safety limits
“Y” or “Δ” resistive loads
DMAK – Aircraft Pitot and Static Adaptor Kits
Complete pitot-static adaptor systems with hoses for all aircraft types
Angle of Attack “Smart” probe adaptors available for specific aircraft types
Compatible with DMA air data testers
Supplied with seal replacements
Vacuum hold-down for static ports
Custom adaptors – design and manufacture
MM14-BW Automated Pressure Calibration System
Better than 25ppm accuracy
Automatic calibration in aircraft pitot and static ranges
High performance Primary Standard pressure balance
Integral Transfer Standard
Unit Under Test (UUT) calibration up to 3.9 bar absolute
Pressure and Vacuum pumps included
MTG 7 – Digital 3 Axis Tilt Table
Digital Test Bench for gyroscopic testing
Microprocessor based system for movement control
Independent control of 3 angles and 3 speeds
Remote control via touch screen and keyboard
Safety Stop buttons – local and remote
Programmable safety limits
PAMB10H / 11H – Precision Pressure Indicator
Single (PAMB 10H) and dual channel (PAMB 11H)
High accuracy transfer standards
Accuracy to ±2 feet at sea level
Air data or pressure units
Colour LCD touch screen
Simultaneous Ps & Qc or Ps & Pt display (PAMB 11H)
EPSR- External Pressure and Vacuum Generator
Vacuum pressure (Ps) to: 7 hPa abs.
Positive pressure (Pt) to: 3500 hPa abs.
On demand running pumps
5,000 hours pump guarantee
Low maintenance design
19 inch 3U rack mount assembly
Larger Pressure Volume generator models available
